Ⅰ. Processing flow

Tank Loading, Circulating water Washing, Brush Washing, Live water Cleaning, Lamp Inspection, Eggs head piercing, 360-degree rotating Pre-cooked, High-temperature cooking, Cooling, Eggshell Peeling machine, Quality Checking

Ⅱ. Technic parameters

Machine Name                               Marinated egg Boiling machine

Model                                           WZL180

Productivity                                   18000pcs/h

Egg request                                   Fresh eggs with a PH above 9.2

Egg Cooking Temperature               around 98℃

Egg Cooking time                           30min

Cooling temperature                         Below 7℃

Peeling type                                   Kneading

Delivery Speed                               0 - 0.5m/s, Steplessly adjustable

Power                                           12.5kw

Power supply                                   380V

Outsize                                           12500x1700x1300mm

Approximate weight                         4700kg

Ⅲ. Machine Features

1. Separate push-button interface, simple and convenient operation;
2. The main structure is made of thick 304 stainless steel, which is firm, non-deformable and long service life;
3. Food contact part is made of food-grade 304 stainless steel, which meets food safety requirements;
4. Main accessories are integrally formed with automatic tools to ensure stable and reliable operation for a long time;
5. Egg breakage rate is low, low employment, high economic efficiency;
6. Key components of the equipment are imported from Germany & the USA, with low wear, low noise and durable.
